Kellermann Atto® DF LED mini indicator 3 in 1 Integral black w/ clear glass

ECE-tested for rear

Clean Look

The Atto® DF Integral is the first built-in version from Kellermann, it can be fully integrated into the fairing or other components. The slim casing almost fully disappears and gives the desired 'clean look' when it comes to customizing.

Behind the extremely small yet sensationally bright Atto® DF Integral lays a multifunctional all-rounder: At the rear it is visually almost completely disguised with a light surface, which would fit four times on a 1 Cent coin! In result the rear of the motorcycle can be designed as clean and individual as never before. However, in action the Atto® DF Integral shines with an intensity which has made Kellermann products legendary – it’s not the size but the illumination power that counts. Indicators, rear and brake light warn with an uncompromising intensity, clearly signalling the following traffic to keep its distance.

Kellermann’s well-known HighPower LED technology** and EXtranz® - Extreme Optical Transparency Technology manage an optimized light channelling through a smart system of lenses and reflectors and thus enabling this combination of sensational brilliance and minimal size. The Atto® DF Integral can be combined with various other series e.g. Atto® or Bullet 1000®.

The complete electronics of the Atto® DF Integral are in the casing, this Atto® DF Integral can be plugged into the 12 volt net directly.*

In order to protect the Atto© DF Integral from a possible thermal overload, a heat sink in the form of an optionally screw-on ribbed housing is provided. Dimensions heat sink approx.: 24.5x8.9 mm

* Possibly electronic equipment is needed to regulate the flashing rate.

** Combination out of the IC operated Longlife Protection Guard® system with high-performance-LEDs latest type of construction.

Casing: black

DC on-board power supply: 12V

ECE-type approval: Motorcycles

Functional features: Brake light, Indicator, Rear light

Length (without thread/fastening): 13,2 mm

Lens colour: clear

Mounting: Built-in article

Mounting thread: M5 x 0,5 x 9,5 mm

Technology: LED

Ø max.: 8,9 mm
